Reflector panels for Mid Power LEDs – 285.60mm x 61mm side, 10.25mm height – 60° FWHM Extra Wide Beam – “PIXEL 11×3 Reflectors”
Reflector panels made of 33 cavity, box-shape, designed for Mid Power LEDs
Module dimensions: 285.60mm x 61mm side, 10.25mm height
“PIXEL 11×3 Reflectors”
Material: Black PMMA + Alluminium Reflective Coating
Full angle at 50% from maximum: ~ 60°
Full angle at 10% from maximum: ~ 90°
The light spots here represented refer to tests carried out with 33 LEDs, 3030 size, ~4686lm@Strip
Product images are for illustrative purposes only. All the data contained in this page are the property of Khatod Optoelectronic Srl and may change without prior notice. Production, marketing, distribution, sale of these products as well as their possible modifications and variations are only and exclusive right of Khatod Optoelectronic S.r.l. No company can perform any of these actions without written permission released by Khatod Optoelectronic S.R.L. – REPRODUCTION PROHIBITED –
